UL1672 電子線

■說明:
●導(dǎo)體使用單條或絞線，裸軟銅或鍍錫軟銅線。
●PVC絕緣，PVC被覆。
●額定溫度：105℃，額定電壓：300volts。
●可通過UL VW-1 垂直耐燃測試。
●使用標準厚度， 易剝， 截斷容易。
●被覆體厚度5-40mils (0.127-1.016mm)
●參考標準：UL 758，UL 1581

■應(yīng)用：
●用于電子及電器設(shè)備內(nèi)部配線。


■PRODUCT DISCRIPTION:
●Stranded or solid,tinned or bare copper conductor.
●Color-coded PVC insulation and PVC jacket.
●Rated temperature：105℃. Rated voltage：300 volts.
●Passes UL VW-1 vertical flame test.
●Uniform thickness of wire to ensure easy stripping and cutting.
●Jacket thickness：form 5 to 40 mils (0.127 to 1.016mm).
●Reference standard：UL subject 758，UL 1581.

■APPLICATIONS：
●Internal wiring of electronic and electrical equipment.
